2WB 2WJ 鎖牙式刀頭 Tungsten steel cutter head
Characteristic
Model : 2WB
Tungsten steel cutter head2WJ 鎖牙式刀頭 Tungsten steel cutter head
Tungsten steel cutter head
鎢鋼平銑刀頭
型號 | 直徑 | 刃長 | 頸徑 | 螺紋 | |
2WJ1004 | 10 | 10 | 9.7 | M05 | |
2WJ1204 | 12 | 12 | 11.7 | M06 | |
2WJ1604 | 16 | 16 | 15.7 | M08 | |
2WJ2004 | 20 | 20 | 19.5 | M10 | |
2WJ2504 | 25 | 25 | 24.5 | M12 |
鎢鋼球型刀頭
型號 | 直徑 | 刃長 | 頸徑 | 螺紋 |  |
2WB1002 | R5.0 | 10 | 9.7 | M05 | |
2WB1202 | R6.0 | 12 | 11.7 | M06 | |
2WB1602 | R8.0 | 16 | 15.7 | M08 | |
2WB2002 | R10.0 | 20 | 19.5 | M10 | |
2WB2502 | R12.5 | 25 | 24.5 | M12 |
鎢鋼圓鼻刀頭
型號 | 直徑 | 刃長 | 頸徑 | 螺紋 |  |
2WR100R | 10*0.5R | 10 | 9.7 | M05 | |
2WR101R | 10*1R | 10 | 9.7 | M05 | |
2WR102R | 10*2R | 10 | 9.7 | M05 | |
2WR120R | 12*0.5R | 12 | 11.7 | M06 | |
2WR121R | 12*1R | 12 | 11.7 | M06 | |
2WR122R | 12*2R | 12 | 11.7 | M06 | |
2WR161R | 16*1R | 16 | 15.7 | M08 | |
2WR162R | 16*2R | 16 | 15.7 | M08 | |
2WR201R | 20*1R | 20 | 19.5 | M10 | |
2WR202R | 20*2R | 20 | 19.5 | M10 | |
2WR203R | 20*3R | 20 | 19.5 | M10 | |
2WR251R | 25*1R | 25 | 24.5 | M12 | |
2WR252R | 25*2R | 25 | 24.5 | M12 | |
2WR253R | 25*3R | 25 | 24.5 | M12 |
