PRODUCTS
HRFBC
Characteristic
Model : HRFBC
| 序號 | 型號 | 刀片座 | D | L | A | B | C | E | 重量 | 適用刀片 |
| 1 | RFBC1012B-M6 | A | 9.8-12.2 | 22 | M6 | 8 | 9.6 |
| 12g | CC*03 |
| 2 | RFBC1012B-60L | A | 9.8-12.2 | 63 |
|
| 9.6 | 10 | 55g | CC*03 |
| 3 | RFBC1214B-M6 | A+B | 11.8-14.2 | 23 | M6 | 10 | 11.6 |
| 17g | CC*03 |
| 4 | RFBC1214B-60L | A+B | 11.8-14.2 | 62 |
|
| 11.6 | 12 | 79g | CC*03 |
| 5 | RFBC1416B-M8 | A+B | 13.8-16.2 | 23 | M8 | 12 | 13.6 |
| 25g | CC*04 |
| 6 | RFBC1416B-70L | A+B | 13.8-16.2 | 73 |
|
| 13.6 | 14 | 122g | CC*04 |
| 7 | RFBC1621B-M8 | A+B | 15.8-21.2 | 28 | M8 | 14 | 15.6 |
| 39g | CC*04 |
| 8 | RFBC1621B-80L | A+B | 15.8-21.2 | 85 |
|
| 15.6 | 16 | 178g | CC*04 |
