TY TY深孔鏟鑽 deep hole shovel drill
Characteristic
Model : TY
TY deep hole shovel drillTY深孔鏟鑽 deep hole shovel drill
TY deep hole shovel dril
| 鏟鑽(側固柄螺旋槽刀桿)-銑床使用排削佳 | |||||||||
| 序號 | 接口 | 鑽尖範圍 | 鑽孔深度 | 型號 | 直柄 | 螺絲 | 扳手 | 牌價 | |
| 長度 | 直徑 | ||||||||
| 1 | 00 | 12.98-15.0 | 64.0 | SLH00-ML020-64N | 50 | 20 | 2102046 | 2502017 | |
| 2 | 114.0 | SLH00-ML020-114N | 50 | 20 | |||||
| 3 | 178.0 | SLH00-ML020-178N | 50 | 20 | |||||
| 4 | 05 | 15.5-17.85 | 64.0 | SLH05-ML020-64N | 50 | 20 | 2102046 | 2502017 | |
| 5 | 114.0 | SLH05-ML020-114N | 50 | 20 | |||||
| 6 | 178.0 | SLH05-ML020-178N | 50 | 20 | |||||
| 7 | 10 | 17.86-21.5 | 118.0 | SLH10-ML025-118N | 56 | 25 | 2102049 | 2502016 | |
| 8 | 168.0 | SLH10-ML025-168N | 56 | 25 | |||||
| 9 | 222.0 | SLH10-ML025-222N | 56 | 25 | |||||
| 10 | 270.0 | SLH10-ML025-270N | 56 | 25 | |||||
| 11 | 15 | 22.0-24.6 | 118.0 | SLH15-ML025-118N | 56 | 25 | 2102049 | 2502016 | |
| 12 | 168.0 | SLH15-ML025-168N | 56 | 25 | |||||
| 13 | 222.0 | SLH15-ML025-222N | 56 | 25 | |||||
| 14 | 270.0 | SLH15-ML025-270N | 56 | 25 | |||||
| 15 | 20 | 24.61-29.0 | 137.0 | SLH20-ML032-137N | 60 | 32 | 2102045 | 2502020 | |
| 16 | 187.0 | SLH20-ML032-187N | 60 | 32 | |||||
| 17 | 237.0 | SLH20-ML032-237N | 60 | 32 | |||||
| 18 | 289.0 | SLH20-ML032-289N | 60 | 32 | |||||
| 19 | 400.0 | SLH20-ML032-400N | 60 | 32 | |||||
| 20 | 25 | 30.0-35.5 | 137.0 | SLH25-ML032-137N | 60 | 32 | 2102045 | 2502020 | |
| 21 | 187.0 | SLH25-ML032-187N | 60 | 32 | |||||
| 22 | 237.0 | SLH25-ML032-237N | 60 | 32 | |||||
| 23 | 289.0 | SLH25-ML032-289N | 60 | 32 | |||||
| 24 | 400.0 | SLH25-ML032-400N | 60 | 32 | |||||
| 25 | 30 | 35.51-41.28 | 165.0 | SLH30-ML040-165N | 70 | 40 | 2102044 | 2502015 | |
| 26 | 210.0 | SLH30-ML040-210N | 70 | 40 | |||||
| 27 | 260.0 | SLH30-ML040-260N | 70 | 40 | |||||
| 28 | 349.0 | SLH30-ML040-349N | 70 | 40 | |||||
| 29 | 35 | 42.0-47.99 | 165.0 | SLH35-ML040-165N | 70 | 40 | 2102044 | 2502015 | |
| 30 | 210.0 | SLH35-ML040-210N | 70 | 40 | |||||
| 31 | 260.0 | SLH35-ML040-260N | 70 | 40 | |||||
| 32 | 349.0 | SLH35-ML040-349N | |||||||
| 33 | 40 | 48.0-55.56 | 232.0 | SLH40-ML040-232N | 70 | 40 | 2102044 | 2502015 | |
| 34 | 350.0 | SLH40-ML040-350N | 70 | 40 | |||||
| 35 | 422.0 | SLH40-ML040-422N | |||||||
| 36 | 45 | 56.0-65.09 | 232.0 | SLH45-ML040-232N | 70 | 40 | 2102044 | 2502015 | |
| 37 | 350.0 | SLH45-ML040-350N | 70 | 40 | |||||
| 38 | 422.0 | SLH45-ML040-422N | |||||||
