SD倒角

D

D1

d

L

ap

T

45°SB C16-16-100L-1T

16

4

16

100

4-16

1

SPMW090304/SCMT09T304

45° C12-4-120L-1T

9

4

12

120

4-9

1

SPMG050204

45° C12-6-120L-1T

11

6

12

120

6-11

1

SPMG050204

45° C12-6-110L-2T

12

6

12

110

6-12

1

SPMG050204

45° C12-8-120L-1T

16

8

12

120

8-16

1

SPMG050204

45° C12-8-120L-1T(加長)

16

8

12

120

8-16

1

SPMG050204

45° C20-9-120L-1T

22

9

20

120

9-22

1

SCMT09T304

45° SD C12-10-110L-2T

19

10

12

110

10-19

2

SPMG050204

45° SD C16-9-120L-1T

17

9

16

120

9-17

1

SPMG050204

45° SD C16-12-110L-1T

24

12

16

110

12-24

1

SPMW090304/SCMT09T304

45° C16-14-120L-1T

20

14

16

120

14-20

1

SPMG090408

45° C20-17-160L-2T

25

17

20

160

17-25

2

SPMG07T308

45° C20-19-120L-2T

32

19

20

120

19-32

2

SCMT09T304

45° C20-19-160L-2T

32

19

20

160

19-32

2

SCMT09T304

45° SD C20-20-130L-2T

33

20

20

130

20-33

2

SPMW090304/SCMT09T304

45° SD C20-20-200L-2T

33

20

20

200

20-33

2

SPMW090304/SCMT09T304

45° SD C20-25-110L-2T

38

25

20

110

25-38

2

SPMW090304/SCMT09T304

45° SD C20-25-160L-2T

38

25

20

160

25-38

2

SPMW090304/SCMT09T304

45° SD C20-25-200L-3T

38

25

20

200

25-38

2

SPMW090304/SCMT09T304

45° SD C20-25-160L-3T

43

30

20

130

30-43

2

SPMW090304/SCMT09T304

45° SD C5-30-200L-2T

43

30

25

200

30-43

2

SPMW090304/SCMT09T304

45° SPK C20-25-130L-2T

39

25

20

130

25-39

2

SEKT1204/SEHT1204

45° SPK C20-30-130L-2T

44

30

20

130

30-44

2

SEKT1204/SEHT1204

45° SD C12-3-100L-1T

13

3.3

12

100

3.3-13

1

SDMB26152

45° SD C16-12-110L-1T

23

12

16

110

12-23

1

SDMB26152

45° SD C20-20-100L-2T

31

20

20

110

20-31

2

SDMB26152

45° SD C20-25-110L-2T

36

25

20

110

25-36

2

SDMB26152

45° SD C20-30-110L-2T

41

30

20

110

30-41

2

SDMB26152

45° SD C20-40-110L-2T

51

40

20

110

40-51

2

SDMB26152

45° SDX C25-40-160L-2T

40

25

25

160

25-40

2

SCMT1204

45° SDX C25-40-200L-2T

40

25

25

200

25-40

2

SCMT1204
